Lets Make A VPN (StrongSwan)

In today’s digital landscape, securing your online connections is more crucial than ever. One effective way to achieve this is by setting up a Virtual Private Network (VPN) using StrongSwan, an open-source tool that implements the Internet Key Exchange (IKEv1 and IKEv2) protocols. This guide will walk you through the process of installing and configuring a StrongSwan VPN server on Ubuntu 24.04, along with instructions for connecting clients from various operating systems.

Why Choose StrongSwan?

StrongSwan serves as a keying daemon, allowing for encrypted connections between hosts. By establishing a VPN, you can securely access resources on your server and its network. This guide will not only cover the server setup but will also detail how to connect clients running Ubuntu, Windows, and macOS.

Prerequisites

Before you begin, ensure you have the following:

• An Ubuntu 24.04 server. If you’re using Linode, you can sign up to receive a $100 credit for your first 60 days.
• Basic knowledge of using the terminal and the sudo command.
• A standard user account with SSH access configured securely.

Installing StrongSwan on Ubuntu 24.04

Step 1: Update Your System

Start by updating your package lists and upgrading installed packages:

sudo apt-get update && sudo apt-get upgrade

Step 2: Install StrongSwan

SSH into your server and install StrongSwan along with necessary plugins:

sudo apt install strongswan strongswan-pki libcharon-extra-plugins libcharon-extauth-plugins libstrongswan-extra-plugins libtss2-tcti-tabrmd0 -y

Step 3: Generate Server Keys and Certificates

Generate your IPsec private key and root certificate:

sudo ipsec pki --gen --size 4096 --type rsa --outform pem > /etc/ipsec.d/private/ca.key.pem

Create and sign the root certificate:

ipsec pki --self --in /etc/ipsec.d/private/ca.key.pem --type rsa --dn "CN=<Your VPN Server Name>" --ca --lifetime 3650 --outform pem > /etc/ipsec.d/cacerts/ca.cert.pem

Next, generate the VPN server’s private certificate:

ipsec pki --gen --size 4096 --type rsa --outform pem > /etc/ipsec.d/private/server.key.pem

You will also need to create the host server certificate. Depending on your setup, you can use either a local resolver or a static IP address.

Step 4: Configure StrongSwan

Enable packet forwarding by editing /etc/sysctl.conf and adding the following lines:

net.ipv4.ip_forward = 1
net.ipv6.conf.all.forwarding = 1

Next, configure StrongSwan by editing the /etc/ipsec.conf file and adding the necessary connection parameters. Here’s an example configuration:

config setup
    charondebug = "ike 1, knl 1, cfg 0, net 1"

conn ipsec-ikev2-vpn
    auto = add
    keyexchange = ikev2
    left = %any
    leftcert = server.cert.pem
    leftsendcert = always
    right = %any
    rightauth = eap-mschapv2

Step 5: Authentication and Access Secrets

Create the /etc/ipsec.secrets file to handle user authentication:

: RSA "/etc/ipsec.d/private/server.key.pem"
username : EAP "<user’s password>"

Your StrongSwan server is now set up to accept client connections. Use the following command to check the status of your IPsec tunnel:

sudo ipsec status

Connecting Clients to the StrongSwan VPN

Ubuntu Client Setup

To connect from an Ubuntu client, install StrongSwan:

sudo apt install strongswan libcharon-extra-plugins

Download the server’s certificate and configure the ipsec.conf and ipsec.secrets files similarly to the server setup.

Windows 10 Client Setup

1. Import the VPN root certificate using the Microsoft Management Console (MMC).
2. Set up a new VPN connection through the Network and Sharing Center, entering the server’s DNS name or IP address along with your credentials.

macOS Client Setup

1. Download the server’s CA certificate and import it into Keychain Access.
2. Set up a new VPN connection in System Preferences, providing the necessary server details and credentials.

Troubleshooting Tips

Common issues often stem from mismatched credentials between the server and client. Additionally, firewall settings may block connections, so ensure these are correctly configured. For further diagnosis, check the StrongSwan log file located at /var/log/syslog.
